16kWh Residential LiFePO4 Battery for Whole Home Backup
· 16kWh Usable Energy Capacity
· 51.2V 314Ah LiFePO4 Battery
· Supports Up to 15 Units in Parallel
· IP67 Waterproof Protection
· Automatic Low-Temperature Heating
· 8000+ Cycle Life
· Built-in Smart BMS Protection
· 16kWh Usable Energy Capacity
· 51.2V 314Ah LiFePO4 Battery
· Supports Up to 15 Units in Parallel
· IP67 Waterproof Protection
· Automatic Low-Temperature Heating
· 8000+ Cycle Life
· Built-in Smart BMS Protection
Next: NO MORE
Reliable High-Capacity Battery Storage for Home Energy Systems
Designed for Solar Energy Storage, Backup Power and Energy Independence
PB-16 is a high-capacity 51.2V 314Ah LiFePO4 battery designed for residential solar energy storage, whole-home backup power, and energy independence applications. With 16kWh usable capacity per unit and support for up to 15 batteries in parallel, the system can be expanded to 241kWh to support large homes, villas, and light commercial energy storage applications. Built with premium lithium iron phosphate (LFP) cells and an intelligent Battery Management System (BMS), PB-16 delivers exceptional safety, long service life, and reliable performance for residential energy storage and backup power applications.
Reliable High-Capacity Battery Storage for Home Energy Systems
Designed for Solar Energy Storage, Backup Power and Energy Independence
PB-16 is a high-capacity 51.2V 314Ah LiFePO4 battery designed for residential solar energy storage, whole-home backup power, and energy independence applications. With 16kWh usable capacity per unit and support for up to 15 batteries in parallel, the system can be expanded to 241kWh to support large homes, villas, and light commercial energy storage applications. Built with premium lithium iron phosphate (LFP) cells and an intelligent Battery Management System (BMS), PB-16 delivers exceptional safety, long service life, and reliable performance for residential energy storage and backup power applications.
 |
IP67 Outdoor Protection IP67-rated enclosure protects the battery against dust, rain, and harsh outdoor environments, enabling reliable indoor and outdoor installation. |
| Automatic Low-Temperature Heating Integrated battery heating supports safe charging in cold climates and helps maintain reliable winter performance. |
 |
IP67 Outdoor Protection
IP67-rated enclosure protects the battery against dust, rain, and harsh outdoor environments, enabling reliable indoor and outdoor installation.
Automatic Low-Temperature Heating
Integrated battery heating supports safe charging in cold climates and helps maintain reliable winter performance.
Technical Specifications
| Battery Model | PB-16 |
| General | |
| Nominal Energy | 16kWh |
| Usable Energy | 16kWh |
| Scalability | Max.15 in Parallel (241kWh) |
| Dimension(H*W*D) | 910*530*255mm |
| Installation | Floor Installation |
| Cell Type | LFP |
| Cell Capacity | 314Ah |
| Design Life | 15 Years |
| Electrical | |
| Nominal Voltage | 512V(16S1P) |
| Operating Voltage Range | 43.2V–56.8V |
| Max.Discharge Current | 200A |
| Max.Charge Current | 150A |
| Operation | |
| Charge Temperature | -10℃–55℃ |
| Discharge Temperature | -10℃–55℃ |
| Storage Temperature | -20℃–45℃ |
| Relative Humidity | 10%-95%（No Condensation） |
| Altitude | ≤2000m |
| Ingress Protection | IP67 |
| Communication Interface | RS485,CAN,WIFI/Bluetooth（Optional） |
| Certification | CE,UN38.3,UL1973,UL5040a(Design conforms) |
| Compatible Inverter | BST,Victron,Goodwe,Solis,Sofar,Deye,Voltronic |
| Battery Model | PB-16 |
| General | |
| Nominal Energy | 16kWh |
| Usable Energy | 16kWh |
| Scalability | Max.15 in Parallel (241kWh) |
| Dimension(H*W*D) | 910*530*255mm |
| Installation | Floor Installation |
| Cell Type | LFP |
| Cell Capacity | 314Ah |
| Design Life | 15 Years |
| Electrical | |
| Nominal Voltage | 512V(16S1P) |
| Operating Voltage Range | 43.2V–56.8V |
| Max.Discharge Current | 200A |
| Max.Charge Current | 150A |
| Operation | |
| Charge Temperature | -10℃–55℃ |
| Discharge Temperature | -10℃–55℃ |
| Storage Temperature | -20℃–45℃ |
| Relative Humidity | 10%-95%（No Condensation） |
| Altitude | ≤2000m |
| Ingress Protection | IP67 |
| Communication Interface | RS485,CAN,WIFI/Bluetooth（Optional） |
| Certification | CE,UN38.3,UL1973,UL5040a(Design conforms) |
| Compatible Inverter | BST,Victron,Goodwe,Solis,Sofar,Deye,Voltronic |
Quality-Driven Manufacturing
Supported by advanced production facilities and internationally recognized management systems, BST ensures consistent quality, operational excellence, and reliable product performance.
ISO 9001 • ISO 14001 • ISO 45001 Certified
Manufacturing-Excellence
Manufacturing-Excellence
Manufacturing-Excellence
Manufacturing-Excellence
Start Your Energy Storage Project with BST
100% Confidential. Drop your contact info to get a quick quote and product datasheet for your project.
